QTLS
12V or 24V AC LED Power Supply - 150W–1500W150-1500W at 12VAC or 24VAC
The QTLS is a single power supply ranging from 150W-1500W. Like the rest of the QT line, this specific product includes every feature and benefit QTL’s development team could think of rolled into one interior power supply. We are focused on making the quietest, most efficient, safest, most versatile, longest-lasting power supply in the industry. The QTLS delivers and comes standard with five taps to allow the installer to fine tune the voltages at the transformer to get as close to the desired voltage at the fixture as possible. The QTLS is also UL listed to be either surface or recess mounted into a 2”x4” stud wall with the ability to install in any thickness drywall.
More About
QTLS
Technical Information
Environment | Indoor (Dry) |
Primary Voltage | 120V@60Hz, 230V@50/60Hz, 277V@60Hz230V & 277V are not standard, call factory for pricing |
Secondary Voltage | 12V, 24V, 5.5V, 120V 5.5V & 120V are not standard, call factory for pricing |
Wattage | 150W, 300W, 500W, 600W, 750W, 900W, 1050W, 1200W, 1350W, 1500W |
Certifications | UL Listed |
Connectivity | Thomas Research |
Dimming Performance | DIM TO BLACK |
Dimming Protocol | Phase |
Driver | Magnetic |
