VERS-ENCAPSULATED (06)
Wet-rated VERSatile fixture encapsulated in polyurethane, providing protection from moisture, dust and dirt
| • Wet-rated VERSatile fixture encapsulated in polyurethane • The polyurethane encapsulation provides optimal delivered lumens • Features integrated metal endcaps • Mounting options include a concealed or magnetic clip • With an internal White Optics coating, the fixture achieves greater lumen output • Durable anodized aluminum housings • Consult factory for field assembly options |
More About
VERS-ENCAPSULATED (06)
Technical Information
| Watts per Foot | 1.5, 3.0, 4.0, 5.0, HE1.5, HE3.0, HE6.0 |
| Finish | Satin, Black, Bronze, White, Custom |
| Mounting | Concealed Clip, Magnet |
| Rated | Encapsulated IK10 |
| Warranty | 5 year |
| Photometric Performance | Encapsulated Clear, Encapsulated Translucent |
| LED Light Engine | Static White High-Efficacy, Dynamic White High-Efficacy, RGBW High-Efficacy, Static White, Dynamic White, Static Color, RGB, RGBW |
| Length | Fixture length min 12", max98.43" not including end caps.Consult factory for lengthsunder 12". |
| Lenses | Encapsulated Clear, Encapsulated Translucent |
| Lumens per Foot | 286 at SW 4.0 w/f |
| CCTs | 2400K, 2700K, 3000K, 3500K, 4000K |
| Certifications | UL Listed, RoHS, Declare. FWC |
| Compatible App | SCENE Dongle |
| Connector Wire | Bare Wire 24", Connector 24", Connector 6" |
| CRI | 96-97 at 3000K |
| Environment | Indoor/Outdoor |
| External Louver | White Plastic, Black Plastic, Satin Anodized AluminumBlack Anodized Aluminum, White Powder Coated Aluminum, No Louver |
| Product Applications | Surface Mount, Cove Lighting, Millwork Lighting |
