ALTA-FLAT (01) LED light extrusion for low-profile light in small areas
ALTA-FLAT (01) LED light extrusion for low-profile light in small areas
ALTA-FLAT (01) MICRO 5 LED fixture with a sleek profile for surface-mounted or recessed installations


1-Bin, 1-Step
UL Listed LED lighting products
RoHS LED lighting product
Title 24 Lighting
NEC Closet Certified
5 Year Warranty
Buy American Act Lighting
Declare Label Approved Lighting
Red List Approved

Micro 5 fixture with a sleek flat profile

The new ALTA-FLAT (01) Micro 5 Series is 55% smaller than TALO making it one of QTL’s smallest fixtures. ALTA’s modern and discreet design is complemented by a sleek flat lens that delivers a superior uniform light output and luminosity, making it ideal for surface-mounted or recessed installations that call for low-profile light in small areas. Mounting options include a mounting clip or a convenient magnet option making installation and repositioning effortless. Available in satin or black finishes and frosted or diffused lenses.

More About MICRO 5 ALTA-FLAT (01)

Technical Information

Watts per Foot 1.0, 2.0, 4.0
Finish Satin, Black, Custom
Mounting Stainless Steel Clip, Magnetic Clip
Rated Dry IP20, Damp IP54
Warranty 5 year
Photometric Performance Diffused, Frosted
LED Light Engine Static White, Dynamic White, RGB
Length Fixture length min 12", max 98.43" not including end caps. Tolerance +0 – 1/8". Consult factory for lengths under 12".
Lenses Frosted, Diffused
Lumens per Foot 323 at SW 4.0 w/f
CCTs 2000K, 2200K, 2400K, 2700K, 3000K, 3500K, 4000K
Certifications UL Listed, RoHS, JA8-2019, 1 Step 1 Bin, Declare, Closet Rated Light Fixture NEC 410.2 and 410.16
Compatible App SCENE Dongle
Connector Wire Bare Wire 24", Barrel 6", Connector 24", Connector 6", Not soldered
CRI 97-98 at 3000K
Dimensions 0.44" x 0.43"
Environment Indoor/Outdoor
Product Applications Surface Mount, Millwork Lighting
