100W LED driver with integrated Lutron Athena Node. Easily programmed via Athena app, connects to Lutron controls via RF mesh network. Offers recessed or surface mounting options
100W LED driver with integrated Lutron Athena Node. Easily programmed via Athena app, connects to Lutron controls via RF mesh network. Offers recessed or surface mounting options

QT-CAB-eLED+0-10V-AWN

LED POWER SUPPLY 60W–600W
CSA Certified
RoHS LED lighting product
Declare Label Approved Lighting
Red List Approved

Features 0-10V dimming, compatible with 12VDC/24VDC products, UL listed for 1-6 drivers and dimming modules, includes factory-installed Lutron Athena Wireless Nodes.

  • Housing can be recessed or surface mounted
  • Type IC rated
  • Features 0-10V dimming
  • Compatible with 12VDC or 24VDC constant voltage products
  • UL listed enclosure allows for 1-6 drivers and 1-6 dimming modules
  • Incorporates factory-installed Lutron Athena Wireless Nodes, which streamlines installation time and allows for simple programming using the Athena iOS and Android app
  • Using radio frequency, it connects seamlessly to Lutron wall controls, keypads, and sensors over a mesh network, providing an efficient lighting control solution.
  • Designed for interior use
More About QT-CAB-eLED+0-10V-AWN

Technical Information

Primary Voltage Universal
Secondary Voltage 12VDC, 24VDC
Wattage Options 1 60W Driver, 2 60W Drivers, 3 60W Drivers, 4 60W Drivers, 5 60W Drivers, 1 100W Driver, 2 100W Drivers, 3 100W Drivers, 4 100W Drivers, 5 100W Drivers, 6 100W Drivers
Control Options 0-10V-AWN-1, 0-10V-AWN-2. 0-10V-AWN-3, 0-10V-AWN-4, 0-10V-AWN-5,0-10V-AWN-6
Mounting Recessed, Surface Mounted
Color White, Black
Environment Dry, Damp
Zones Up to (6) primary zones
Warranty 5 years
