KICKER ENCAPSULATED (03) is a polyurethane-filled asymmetrical LED light fixture with 100° focused beam 30° off-nadir
 KICKER ENCAPSULATED (03) is a polyurethane-filled asymmetrical LED light fixture with 100° focused beam 30° off-nadir
KICKER-ENCAPSULATED 03
KICKER-ENCAPSULATED 03
KICKER-ENCAPSULATED 03 DIMENSIONS
KICKER-ENCAPSULATED 03 BEAM ANGLE

MICRO 5 KICKER-ENCAPSULATED (03)

1-Bin, 1-Step
UL Listed LED lighting products
RoHS LED lighting product
NEC Closet Certified
Recessable
5 Year Warranty
Buy American Act Lighting
Declare Label Approved Lighting
Red List Approved

Polyurethane-filled asymmetrical fixture with 110° focused beam 30° off-nadir

  • MICRO 5 Series linear LED fixture engineered for exceptional light quality and even distribution, seamlessly blending with millwork details
  •  Asymmetrical fixture with 110° focused beam 30° off-nadir
  •  Features high quality LED strips encapsulated in polyurethane in a rigid extrusion providing a robust fixture
  •  Encapsulation available in translucent
  •  Suitable for indoor and outdoor locations
  •  Ideal for recessed installations that call for low-profile light in small areas
  •  Suitable for installation in the storage area of a clothes closet when specified with LEDs at 4.0 watts or less per foot per NEC regulations
More About MICRO 5 KICKER-ENCAPSULATED (03)

Technical Information

Watts per Foot 1.0, 2.0, 4.0
Finish Satin, Custom
Mounting Silicone
Rated Encapsulated IP67
Warranty 5 year
Photometric Performance Translucent
LED Light Engine Static White, Dynamic White, RGB
Length Fixture length min 12", max 98.43" not including end caps. Tolerance +0 – 1/8". Consult factory for lengths under 12".
Lenses Encapsualted Translucent
Lumens per Foot 199 at SW 4.0 w/f
CCTs 2700K, 3000K, 3500K, 4000K
Certifications UL Listed, RoHS, 1 Step 1 Bin, Declare, Closet Rated Light Fixture NEC 410.2 and 410.16
Compatible App SCENE Dongle
Connector Wire Bare Wire 24", Barrel 6", Connector 24", Connector 6", Not soldered
CRI 97 at 3000K
Dimensions 0.71" x 0.41"
Environment Outdoor
Product Applications Linear Recessed, Millwork Lighting
