96W power supply in Q-VAULT-5 with DMX capabilities for versatile LED outputs. Compatible with QTL NFC App for DMX and voltage adjustments.
96W power supply in Q-VAULT-5 with DMX capabilities for versatile LED outputs. Compatible with QTL NFC App for DMX and voltage adjustments.
Voltage Drop Calculator

Q-SET+QZ-DMX

CSA Certified
Pool & Spa Rated
5 Year Warranty
Declare Label Approved Lighting
Red List Approved

96W at 24VDC

Q-SET+QZ-DMX is QTL's direct burial and outdoor rated electronic power supply to be installed in our Q-VAULT-5 enclosure. A versatile Class 2 LED driver, the Q-SET+QZ-DMX is available with DMX capabilities. It features up to 4 channel outputs that can power static white, static color, warm dim and dynamic color LED products. The Q-SET+QZ is powered at 110-277V and provides a secondary voltage of 24VDC. It is available in 96 watt and is fully listed for direct burial use when installed in the Q-VAULT. Additionally, it is compatible with the QTL NFC App for reading and writing DMX addresses and adjusting output voltage.

More About Q-SET+QZ-DMX
Technical InformationVideosRelated Products

Technical Information

Environment Landscape
Primary Voltage Universal (120V-277V)
Secondary Voltage 24V
Warranty 5 year
Wattage 96W
Certifications CSA
Dimming Performance DIM 0.1%
Dimming Protocol DMX
Driver Electronic
