QTMS
12V or 24V AC LED Power Supply - 60W–750W
60 - 750W at 12 or 24VAC
The QTMS is a single power supply ranging from 60W-750W. Part of the QT Series, the quietest, most efficient, safest, most versatile, longest-lasting power supplies in the industry, the QTMS AC power supply comes standard with five taps to allow the installer to fine-tune the voltages at the transformer to get as close to the desired voltage at the fixture as possible. The QTMS is UL listed to be either surface or recess mounted into a 2”x4” stud wall with the ability to install in any thickness drywall.
More About
QTMS
Technical Information
| Environment | Indoor (Dry) |
| Primary Voltage | 120V@60Hz, 230V@50/60Hz, 240V@50Hz, 277V@60Hz230V & 240V not standard, call factory for pricing |
| Secondary Voltage | 12V, 24V, 120V 120V not standard, call factory for pricing |
| Wattage | 60MV, 100MV, 150MV, 300MV, 500MV, 600MV, 750MV |
| Certifications | UL Listed, CSA, Declare, Red Listed |
| Connectivity | Thomas Research |
| Dimming Performance | DIM TO BLACK |
| Dimming Protocol | Phase |
| Driver | Magnetic |
| Warranty | 10 Year |
