Q-CAP | MICRO 5 Series
UL Listed LED lighting products
RoHS LED lighting product
5 Year Warranty
Declare Label Approved Lighting
Red List Approved
Buy American Act - Select Light Engines, See Spec Sheet

Flexible micro-fixture with 6" up/down radius

  • Fully encapsulated flexible fixture with up/down bending capabilities
  • 60% smaller than QTL's standard fixture (BOXA)
  • Available in a seamless option, where wires are hidden, allowing for long runs of light
  • Perfect for indoor or outdoor applications and direct or indirect view
  • 6” bend radius
  • Utilize clear endcaps for continuous runs with no light loss
  • Available in Static White, RGB, and DW for Tunable Applications, and DW for Warm Dim Applications
    2022 IES Progress Report Award Winner

  • Specify a 4' piece of field cuttable Q-CAP for precise run length adjustments on-site, enabling orders before construction is complete and allowing for jobsite modifications (dry applications only)

CONFIGURE WAVE
More About Q-CAP WAVE
Technical InformationVideosRelated Products

Technical Information

Rated Dry IP20, Wet IP67
Seamless Available in a seamless option
Warranty 5 year
Bend Orientation Up/Down Bend
Bend Radius 6" bend radius
CCTs 2400K, 2700K, 3000K, 3500K, 4000K, 2400K-3000K, 2700K-4000K
Certifications UL Listed, RoHS, Declare
Compatible App SCENE Dongle
Connector Wire Bare Wire 24" Barrel, Connector 6", Connector 24"
CRI 95-96 at 3000K
End Caps Clear, White
Environment Indoor/Outdoor
LED Light Engine Static White, Dynamic White Tunable Applications, Warm Dim, RGB
Length Fixture length min 12", max 191". Consult factory forlengths under 12". Available in 1" increments.
Lenses Encapsulated Clear, Encapsulated Translucent
Mounting White Snug Clip, PVC Clip, PVC Channel, Low Profile PVC Clip, Low Profile PVC Channel, 16' BENDIT Up/Down Stainless Steel Channel, 32' BENDIT Up/Down Stainless Steel Channel, 16' BENDIT Up/Down White Stainless Channel, 32' BENDIT Up/Down White Stainless Channel
Photometric Performance Encapsulated Clear, Encapsulated Translucent
