100-300W at 24VDC LED power supplies with DMX decoder

QOM-eLED is QTL's exterior rated surface mounted electronic DMX DC power supply, utilizing a 100W constant voltage LED Driver from Thomas Research and the LINEARdrive DMX decoder from eldoLED. With the ability to fit up to 300W of power and control in one enclosure, this unit provides plenty of flexibility and comes with all decoders prewired together with terminal blocks for landing your RGB or RGBW wires.

More About QOM-eLED+DMX
Technical InformationVideosRelated Products

Technical Information

Environment Indoor (Dry), Outdoor (Wet)
Primary Voltage Universal (120V-277V)
Secondary Voltage 24VDC
Warranty 5 year
Wattage 100W, 200W, 300W
Certifications CSA, RoHS
Connectivity ELDO
Dimming Performance DIM 0.1%
Dimming Protocol DMX
Driver Electronic
