NEXUS flexible linear led lighting
NEXUS flexible linear led lighting
Q-CAP NEXUS DIMENSIONS
Nexus_application
CONFIGURE NEXUS
Calculate Q-CAP NEXUS Length

Q-CAP NEXUS

Q-CAP | MICRO 5 Series
UL Listed LED lighting products
RoHS LED lighting product
5 Year Warranty
Declare Label Approved Lighting
Red List Approved
EPD Verified
IES Progress Report
Buy American Compliant Lighting SW, SW-HE, DW-HE
Buy American Act Compliant SW, SW-HE, DW-HE
Build America, Buy America Compliant SW, SW-HE-DW-HE Only

Flexible micro-fixture with helical and up/down bend orientations, IK10 impact rated

  • Flexible encapsulated LED fixture with 4" bend radius
  • Features helical bend and up/down bending capabilities
  • Rated for both interior and exterior use, offering versatility for various environments
  • 2022 IES Progress Report Award Winner

  • Specify a 4' piece of field cuttable Q-CAP for precise run length adjustments on-site, enabling orders before construction is complete and allowing for jobsite modifications (dry applications only)

CONFIGURE NEXUS
Calculate Length
More About Q-CAP NEXUS
Technical InformationVideosRelated Products

Technical Information

Rated Dry IP20, Wet IP67
End Caps White Endcaps
Mounting White Snug Clip, 16' BENDIT Up/Down Stainless Steel Channel, 32' BENDIT UP/DOWN Stainless Steel Channel, 16' BENDIT Up/Down White Stainless Channel, 32' BENDIT Up/Down White Stainless Channel
Warranty 5 year
Wattage 1.0W-SO, 2.0W-HO, 4.0W-VHO
Photometric Performance Encapsulated Clear, Encapsulated Translucent
Environment Indoor/Outdoor
LED Light Engine Static White
Lenses Encapsulated Clear, Encapsulated Translucent
Bend Orientation Helical, Up/Down Bend
Bend Radius 4" bend radius
CCTs 2400K, 2700K, 3000K, 3500K, 4000K
Certifications UL Listed, RoHS, Declare, EPD Verified Product
Compatible App SCENE Dongle
Connector Wire Bare Wire (Standard 24")
CRI 96,98 at 3000K
