30-60W at 24VDC LED Driver
30-60W at 24VDC LED Driver
Low profile versatile dimmable Class 2 DC LED driver
Class 2 DC LED driver that can be controlled via phase (forward or reverse) or 0-10V dimming
Voltage Drop Calculator

QZLP

24V DC Low Profile LED Power Supply - 30W - 60W
FCC tested
UL Listed LED lighting products
RoHS LED lighting product
5 Year Warranty
Declare Label Approved Lighting

30W-60W at 24VDC LED Driver

  • Low profile design
  • Versatile dimmable Class 2 DC LED driver
  • Can be controlled via: Phase (forward or reverse), 0-10V dimming
  • Pulse Width Modulation (PWM) output: provides smooth flicker-free dimming
  • Recommendation when using phase control: use a dimmer with a neutral is recommended
  • Output specifics  24VDC constant voltage output
  • Available in: 30W & 60W
  • Operating temperature range: -40°F to +140°F
  • Listed for indoor use
Voltage Drop Calculator
More About QZLP
Technical InformationVideosRelated Products

Technical Information

Environment Indoor (Dry)
Primary Voltage Universal
Secondary Voltage 24V
Warranty 5 Year
Wattage 25W, 30W, 60W
Certifications UL Listed, FCC, RoHS, Declare
Dimming Performance DIM 0.1%
Dimming Protocol Phase, 0-10V
Driver Electronic
